MultiConnect rCell 600

Industrial Wireless Router

4G LTE  Industrial Cellular Router  -  USA and Canada

LTE OnGo CBRS Industrial Cellular Router

MultiConnect® rCell 600 Series cellular routers offer intelligent software and flexible industrial hardware interfaces to provide highly reliable, redundant, and secure connections for high-throughput enterprise assets and SCADA applications. With LTE Cat 12 OnGo CBRS (Citizens Broad Band Radio) shared wireless spectrum, the MultiConnect rCell 600 Series is perfect to enable Field Area Networks (FAN) with high-speed access to the internet without compromising performance or interfering with existing wireless networks. Dual-SIM card, data storage, and seamless power failover capabilities add an extra layer of confidence when maintaining operations that require continuity of service in environments where system disruption is not an option. DeviceHQ®,builtintoyourMultiConnectrCellpurchase, includes remote provisioning, Over-The-Air network diagnostics, and firmware updates so you can securely deploy, manage and scale your solution fast.

Key Features

• FCC Part 96 Authorized end device for Band 48 OnGo CBRS networks
• Approved interoperability with CBRS infrastructure vendors
• Dual-SIM LTE module with failover
• Wi-Fi Compliance IEEE802.11n/ac 2T2R; Multiple (8) SSIDs for privilege group devices or users
• 4x10/100/1000LANportswithtagbasedand port-based VLANs easily to group control and relocate traffic pattern
• Two-wire RS232/RS485 interface for Modbus RTU and various serial communication protocols, and DI/DO for device triggering or event reporting
• Multi-mode data logging function and store collected logs on attached storage for SCADA telemetry
• Fully protocol with NAT/Routing/IPv6 compatible with most IP network
• IPSec, OpenVPN, PPTP, and L2TP VPN support up to 16 concurrent tunnels with max 100Mbps throughput (IPSec)
• A firewall with SPI and IPS functions prevent hackers from attacking and enhance network efficiency
• SNMP, Telnet CLI, Web UI, TR-069, and DeviceHQ for administration and device management
• QoS and Bandwidth Management for optimal bandwidth usage
• Seamless power failover between redundant DC 12V~48V wide range power input

MultiConnect rCell 500 Details

• The rugged and industrial MultiConnect® rCell 600 Series CBRS router, supporting up to 128 simultaneous Wi-Fi connections, can be deployed to create a super mobile Wi-Fi hot spot within vehicles, ideal for Wi-Fi mobility within construction sites and oil fields where worker productivity requires reliable Wi-Fi coverage on the go without known dead spots at difficult to connect locations. Also within school busses, libraries, community centers, and other venues where wired backhaul and social distancing is possible– while eliminating the expensive data cost and plan restrictions associated with traditional cellular-enabled data plans.
• The MultiTech commitment to service means we provide a two-year product warranty and service that includes free technical support, 24-hour website, and FTP support.

MultiConnect rCell 500 Applications

• Wi-Fi Mobility
• Constructions Sites
• Oil and Gas
• Vehicles
• School Busses
• Libraries
• Community Centers
• Venues where wired backhaul and social distancing is possible– while eliminating the expensive data cost and plan restrictions associated with traditional cellular-enabled data plans

Product Specifications

DATA SHEETS

Data Sheet:  MultiConnect rCell 600

Have more questions about Industrial Wireless Router solutions? Need to Purchase Multitech Industrial Wireless Router Products? Call us at 410-583-1701 or email us at questions@pulsesupply.com.
